Written by Brendon McHugh and Kaue Mocellas

Friday, April 29, 2022 | Comments

With the exponential growth of the Internet of Things (IoT), the world is becoming increasingly interconnected with the possibility that most devices, from home electronics to self-driving cars, will be wirelessly connected to the network in the near future. Although the huge connectivity of devices is great for technological advances towards more intelligent and automated devices, it raises many questions and concerns about the security aspect of RF connections as devices become more susceptible to signal interception, eavesdropping, forgery, unauthorized command and other security threats. This problem ranges from user equipment (UE), small cell base stations, and the large core radio access network (RAN) itself.

Program-defined radio (SDR) is not only capable of executing such threats, but also provides the means to detect vulnerabilities in the physical (PHY) layer of protocol stacks. In this article, we discuss various tools for assessing / troubleshooting device security using SDR. Discussion includes RF fuzz testing using SDR software to debug low-level RF and hardware protocols, and PHY / MAC analysis; and penetration testing in which wireless receivers are forged or attacked to assess vulnerability. Using SDR, these techniques can be easily achieved by developing algorithms in GNU Radio and / or Python.

Why the US needs a single cyber security framework

It is not too early to prepare for 6G

Technology-based hybrid warfare: the need for cybersecurity endpoint

Vulnerabilities of RF devices

RF signals are a fundamental part of wireless communication and are used in satellite signals (GPS), mobile network towers, LAN modems for Wi-Fi, and everyday gadgets such as garage door controllers. The principle is quite simple: a modulated carrier signal is used to transmit information via electromagnetic waves. There are several modulation techniques in both the market and scientific literature, including amplitude shift (ASK), quadrature amplitude modulation (QAM), and phase shift (PSK). The general configuration of the RF transmitter and receiver is shown in Figure 1. In the receiver, the antenna receives the signal, amplifies it to obtain a manageable amplitude, and demodulates to obtain information. On the transmitter side, the carrier is modulated using digital data, amplified to optimize RF transmission, and sent to the antenna.

Because radio frequency signals are not bound to a limited physical medium, they are available through the air and can be easily picked up by anyone with an antenna and receiver, creating a very risky scenario for malicious threats. This problem has increased with the rapid development of receivers and demodulators, which have become cheap for the average user in a way that almost anyone can intercept and track RF signals. In addition, the Bluetooth Low Energy (BLE) and IoT communication protocols have only recently been adopted by industry, so developers and security tools are not yet fully ready for devices with multiple RF inputs / outputs. Some examples of radio-based device vulnerabilities include Philips Hue (Zigbee Worm), Keysniffer, SweynTooth, BlueBorne Exploitation, BleedingBit, and Mouse Jack.

Frequent RF attacks

The most obvious attack in RF-based communication systems is espionage. It consists of detecting, reading (eavesdropping) and monitoring wireless devices for malicious purposes. It can be used to obtain private information about individuals by intercepting mobile phones, wearables and health performance monitors. In addition, the highly interconnected Internet of Things infrastructure of modern businesses is a critical vulnerability, as virtually any compromised IoT device can serve as a gateway for leaking confidential information and access to a company’s network. Looking ahead, even wireless mice and keyboards can be used to access remote PCs using an attack called MouseJack, which works by sending fake command packets to exploit unencrypted USB keys and retrieve the victim’s computer.

The problem becomes even more critical in the context of the Industrial Internet of Things (IIoT). This term is widely used in the technology industry to denote highly interconnected structures of sensors, actuators, computers, and manufacturing equipment that communicate with each other wirelessly. Common attacks in IIoT structures include device hijacking, data extraction, and denial of service. The first attack, device hijacking, describes the unauthorized control of an IoT device by a malicious person. Data extraction, also called data siphoning, is an attack aimed at obtaining confidential data transmitted over the IIoT network. Finally, a denial-of-service attack is used to disable end devices and the network itself by flooding communication links with useless data traffic.

In any case, network attacks will always take advantage of the wireless network architecture implemented in the IIoT structure, so it is important to contextualize attacks with the most common wireless technologies in the industry. One of the most widely used technologies today is Long Range (LoRA), a low-power WAN (LPWAN) technology that uses a modulation scheme based on a scattered chirp spectrum. LoRA is used in several industrial applications, including smart meters, detection and tracking, the Internet of Things, smart agriculture, and climate monitoring. Other examples of technologies are mobile networks, including 4G / LTE and 5G, and Zigbee, which is used to create network networks based on the Advanced Encryption Standard (AES) -128 encryption scheme. With regard to cellular networks in particular, the IIoT market is divided into LTE-M and narrowband IoT (NB-IoT). In addition, access to the Global Navigation Satellite System (GNSS) / GPS, which is required by several IoT devices in the industry, can be used for counterfeiting and disruption attacks, causing malfunctions and jeopardizing basic operations.

To better understand and prepare for RF attacks, it is important to implement a threat classification and description model. This model can be combined with a network system model to assist in decision making and threat detection / classification. One of the most commonly used systems is the STRIDE model, which is described in Table 1. The STRIDE model classifies threats into six different categories, each threatening a specific network property desired in the system. By categorizing security threats in the IoT network using STRIDE, we can identify potential schemes to prevent and mitigate their effects before they occur. The table below shows a description of each STRIDE threat and a property that will be compromised if the attack materializes. From an Internet of Things perspective, the description of each threat should be contextualized for the application. For example, in RFID-based systems, an attack aimed at changing the serial number in a tag to match another person’s number is classified as tampering, and tracking someone’s position using RFID tags falls into the category of information disclosure.

SDR to attack wireless devices

SDRs are amazing versatile radio devices that perform most complex computer operations on the software side instead of on the hardware side. The emergence of SDR was a shift in the analogue radio paradigm that significantly improved the flexibility, reliability, robustness, and cost-effectiveness of complex and well-structured radio systems. SDRs can be designed in a variety of forms, from USB keys to full 3U shelving units and several different prices ranging from 10 to a few hundred dollars. Regardless of price and design factor, however, SDR can generally be divided into three parts: radio interface (RFE), digital backend, and mixed-signal interface (Figure 1). RFE consists of an irreplaceable analog circuit required to perform basic functions such as amplification, antenna impedance matching, and radio tuning. A typical RFE channel consists of a receiver (Rx) and a transmitter (Tx), and one RFE can have multiple channels in multiple inputs and multiple outputs (MIMO) SDRs. In high-end SDRs, RFE modules can achieve 3 gigahertz of current bandwidth over multiple MIMO channels with a tuning range from close DC to 18 GHz.

The digital background consists of a programmable port array (FPGA) to perform highly parallel data calculation that provides high-performance digital signaling process (DSP) functions (sewerage, sampling rate conversion) and network operations (routing, encryption, modem error correction, etc.). In addition, the use of the FPGA allows a complete reconfiguration of the digital processing circuit without replacing the hardware with simple FPGA programming. This means that SDRs are extremely flexible and can work with several different protocols in the same unit. This is desirable when testing network security, as the same device can be used on different networks. The digital background also communicates with the host computer, and the higher-end SDRs provide high-speed optical connections (qSFP +) for high-performance data communication. Finally, the mixed-signal interface is responsible for connecting the RFE to the digital background and is implemented by the ADC and DAC. Figure 1 shows the basic architecture.

Due to the programmable nature of FPGAs, SDRs can be used in RF attacks. For example, very simple SDRs are used to hack into car keys by exploiting security threats in popular models. For example, to prevent replay attacks where an attacker copies the last code sent by the pendant, modern vehicles use a security code to never use the same code twice. However, some Subaru models do not use any sophisticated code generator to replace the current code after use, but simply increase the code. This can be easily exploited by hackers: the SDR built into the USB key, combined with the Raspberry-Pi, can read code sent by the original user, decode the packet using SDR, augment one unit in the code, and retransmit the augmented code to fool car receiver. Therefore, detecting and mitigating network security threats is a fundamental step in designing any IoT device.

In a more general sense, SDRs can be used to break into any IoT system, and a typical process can be divided into four stages:

• Capture / record. At this stage, the signal is simply measured with RFE, digitized and stored in digital background memory cells.

• Demodulation. The demodulation scheme, symbol speed and other basic communication properties must be obtained. If these properties are already known, it is easy to implement a demodulator in SDR. If not, sophisticated algorithms, which sometimes perform artificial intelligence, must be implemented to obtain a modulation scheme.

• Decoding. Most confidential data is encrypted; therefore, it is important that the SDR or host has the means to decode the binary data after demodulation.

• Exploitation of information. Finally, the decrypted information is used to achieve the purpose. This goal may be to obtain sensitive information, interfere with the data sent, or use the data to gain control of the device. In the case of some car key fobs, the data obtained was used in a replay attack where the decoded code was simply augmented and retransmitted.

Protection, prevention, testing

As already mentioned, replay attacks can pose significant threats to the security of the Internet of Things. The most basic algorithm to combat this threat is the current code algorithm, also called the jump code. It basically consists of re-generating the command code after each download, making it impossible for a hacker to use the old code to exploit. The most basic current code algorithms use pseudo-random number (PRNG) generators in both the transmitter and receiver, so that new code can be compared. For Wi-Fi, the most popular algorithm is Wi-Fi Protected Access (WPA). WPA uses the Key Time Integrity Protocol (TKIP) as an encryption protocol, based on keys that change after each packet transmission. WPA2 is a version that can implement Extensible Authentication Protocol (AES), which is a more sophisticated encryption scheme than TKIP (although significantly more difficult). WPA also uses the Pre-Shared Encryption Protocol (PSK) to protect the communication line, which is easily implemented with personal passwords.

In IoT networks, especially in IIoT infrastructures, authentication is significantly more demanding due to the heterogeneity of devices in the same network. Therefore, more dedicated security systems are needed. One example is time-based one-time password authentication (TOTP), where a single-use password is created by adding the uniqueness of the current time in advance to a shared secret key. Of course, latency and clock synchronization must be taken into account when developing basic TOTP networks.

While it may be naive to think that an IoT network can become completely threat-free, this should be the main goal of designers. One idea is to combine more than one security protocol to increase robustness. For example, a key move algorithm can be combined with a two-way handling protocol to obtain key security and a synchronized communication line. The principle of operation is simple: the key rotation algorithm provides a different key after each transmission, and a two-way handshake prevents desynchronization between the transmitter and receiver by external agents.

What message request does CoAP uses for updates?

SDR for device security testing See the article : 5G research by DARPA will lead to commercial applications.

One of the most popular wireless protocols is the LoRA network. It defines the physical (PHY) layer of the network and leaves the top layers to other technologies such as Long Range WAN (LoRAWAN). To assess the safety of LoRA systems, the test should focus on the first identification of the carrier frequency, which for most LoRA applications is below the GHz; modulation scheme; and encryption standard. In this context, the combination of SDRs with GNU radio libraries provides a powerful and convenient framework for evaluating LoRA networks. Since most operations are programmed in the FPGA, the SDR can be easily adapted to any LoRA specification. The test module can capture and decode LoRA PHY signals and implement an interpreter in GNU Radio for data analysis and exploitation.

What message does CoAP use for updates?

SDRs can also be used to perform penetration tests. These tests are designed to simulate a cyber attack on a computer or IoT device to check for network vulnerabilities. The information gained from the tests is then used to configure applications to overcome potential threats and increase network security. An interesting tool for penetration tests has recently been developed using GNU Radio and the Scapy framework. To see also : Global 5G Infrastructure Equipment Market. Scapy-radio is basically a generic wireless control device / injector used to assess penetration in various applications. In a case study, Scapy-radio was validated in systems using the Z-Wave wireless protocol commonly used in home automation systems. SDR-based penetration tests have also been validated in the BLE and Zigbee RF protocols, demonstrating its versatility and wide impact in the Internet of Things community. The study showed that SDRs are an important tool for experiments involving penetration attacks.

Which is the request response layer message present in CoAP?

Fuzzing, fuzz testing, is a well-known liability check in software. This is an automated method that simply enters random, invalid, or unexpected data into the software input, and the results are monitored to diagnose problems such as errors, crashes, and memory leaks. In the context of a wireless network, fusing can be performed using an SDR-based module to expose the physical layer as well as the Media Access Control (MAC) layer of the structure, which is essential for finding contingent liabilities.

Which of the message requests is used in CoAP to update get delete put push?

SDRs can also be implemented to evaluate the effectiveness of the IEEE 802.15.6 standard in wireless body networks (WBANs). WBAN is gaining a lot of attention in the IoT community with the recent boom in wearable technology and the adoption of public health monitoring. However, IEEE 802.15.6 accepts three different types of communication: narrowband (NB), ultra wideband (UWB) and human body communication (HBC), so different WBANs represent different modulation, encryption and frequency specifications, which affects performance and complicates create a generalized evaluator for all WBAN implementations. In this case, SDRs can be extremely useful, as the digital background FPGA can be easily configured to meet the WBAN specifications being tested. This means that with a single ready device, almost any WBAN implementation can be evaluated with minimal hardware adjustments. The general architecture of the SDR used in safety assessment can be seen in Figure 4.

What is CoAP SMS?

This article discusses the main aspects of network security and the potential threats that can jeopardize the proper functioning of wireless networks, including the Internet of Things, the Internet of Things, and mobile communications. We also discussed modeling threats with the STRIDE standard. In addition, we reviewed the key features of SDRs, their potential role as key agents of RF attacks, and why they are so important in testing and measuring security. SDRs can be used in penetration tests, LoRA network validation, WBAN standards assessment, and fuzz testing. SDRs are fundamental tools in designing secure and robust wireless networks that provide flexible and reliable network algorithms to validate your security schemes. They also provide a wide range of size, weight and power (SWaP) characteristics to suit most RF structures. High-end SDRs are available on the market with configurations designed to satisfy even the most demanding applications.
